| Model Name |
InBioPC-800 |
| Display |
N/A |
| Onboard Visual Indicator |
POWER, RUN, LAN, FIRE, AUX IN, DOOR status indicators |
| Operating System |
Linux |
| CPU |
Dual Core @ 1.0 GHz |
| RAM |
128 MB |
| ROM |
256 MB |
| Authentication Method |
Card / Password / Fingerprint / QR Code |
| Access Point Capacity |
Onboard Access Point: 0; Max Access Point: 8 with DE10 Door Unit |
| Fingerprint Template Capacity |
4,000 (1:N) |
| Card Capacity |
40,000 (1:N) |
| QR Code Capacity |
40,000 |
| Supported Biometric Algorithm |
ZKFingerprint V10.0 |
| Max. Card Length |
Up to 66 bits |
| User Capacity |
40,000 |
| QR Code Support |
Dynamic QR Code via ZKBio Zexus Mobile App; Static QR Code: Data Matrix, PDF417, GS1 Databar, Code 128 / EAN128, UPC / EAN, Codabar, Code 39 / 93 |
| Transaction Capacity |
200,000 |
| Communication |
TCP/IP × 1; Wi-Fi IEEE 802.11b/g/n, 1T1R @ 2.4 GHz |
| Inputs |
1 × AUX Input, 1 × FIRE |
| Outputs |
1 × Form C Relay for AUX Output; 1 × Form C Relay for Alarm |
| Standard Functions |
Webserver, Up to 14-digit User ID, Access Levels, Access Groups, Holidays, Anti-passback, Anti-tailgating, Linkage, Global Linkage, Multiple Verification Methods |
| Verification Speed |
< 0.3 sec (Fingerprint) |
| Power Input |
AC 100V–240V |
| Power Output |
8 × PoE, IEEE 802.3at PSE @ 30W |
| Operating Temperature |
0°C to 45°C |
| Operating Humidity |
20% to 80% RH, Non-condensing |
| Dimensions |
440 × 180 × 45 mm (L × W × H), Standard 1U Server Rack Size |
| Gross Weight |
2.825 kg |
| Net Weight |
2.179 kg |
| Supported Software |
ZKBio CVSecurity |
| Mobile App |
ZKBio Zexus |
| Installation |
Rack-mount / Wall-mount / Desktop |
| Housing Material |
SGCC Steel (Steel Galvanized Cold Commercial) |
| Factory ID |
AC02-CB608H-16 |
| Certifications |
ISO 14001, ISO 9001, CE, FCC, RoHS |
