| Model |
KF1100 Pro |
| Camera |
Dual Camera @ 2MP |
| Operating System |
Linux OS |
| Hardware |
CPU: 1.2GHz Dual Core |
|
RAM: 256MB |
|
ROM: 512MB |
| Authentication Method |
Face / Card |
| Face Template Capacity |
3,000 (Face Reader Mode – InBio Pro Plus Default) |
|
1,500 (A&C Standalone Mode – 1:N with DM10, Optional) |
| Card Capacity |
100,000 (Face Reader Mode – InBio Pro Plus Default) |
|
30,000 (A&C Standalone Mode – 1:N with DM10, Optional) |
| User Capacity |
100,000 (Face Reader Mode – InBio Pro Plus Default) |
|
30,000 (A&C Standalone Mode – 1:N with DM10, Optional) |
| Transaction Capacity |
500,000 (Face Reader Mode – InBio Pro Plus Default) |
|
100,000 (A&C Standalone Mode – 1:N with DM10, Optional) |
| Recognition Speed |
≤ 0.3 sec (Facial Recognition) |
| Recognition Distance |
30cm – 50cm |
| Lighting Condition |
≤ 2,000 lux |
| FAR |
≤ 0.01% |
| FRR |
≤ 0.02% |
| Biometric Algorithm |
ZKLiveface 3.5 / 4 |
| Card Type |
ID Card 125 kHz (Standard) |
|
IC Card 13.56 MHz (Optional) |
| Communication |
RS-485 ×1 (Face Reader Mode) |
|
TCP/IP ×1 (Standalone / Face Template Mode) |
|
Wi-Fi 2.4 GHz (Optional) |
| Standard Functions |
Face Reader Mode (with InBio Pro Plus) |
|
A&C Standalone Mode (with DM10) |
|
Face Template Mode (Default) |
| Optional Functions |
IC Card 13.56 MHz |
|
Wi-Fi 2.4 GHz |
| Access Control Interface |
Standalone Mode (with DM10) |
| Power Supply |
DC 12V 3A |
| Operating Temperature |
-10°C to 50°C |
| Operating Humidity |
10% – 90% RH (Non-condensing) |
| Dimensions |
91 × 91 × 13.8 mm |
| Gross Weight |
0.36 Kg |
| Net Weight |
0.27 Kg |
| Supported Software |
ZKBio CVSecurity |
| Installation |
Wall-mounted (Asian Gang Box Compatible) |
| Housing Material |
Aluminium Alloy |
| Certifications |
ISO14001, ISO9001, CE, FCC, RoHS |
| Factory ID |
AC01-VL06H-P17 |
