| Brand |
Manufacturer |
ZKTeco |
| Model |
Variants |
SpeedFace-V5L / SpeedFace-V5L-RFID / SpeedFace-V5L[QR] |
| Order ID |
Product Codes |
V5L: AC01-SP14H-P47 · RFID: AC01-SP12H-P47 · QR: AC01-SP15H-P47 |
| Display |
Screen |
5″ ISP Color LCD (720×1280) |
| Camera |
Type |
Binocular Camera @ 2MP WDR |
| Operating System |
OS |
Linux |
| Hardware |
CPU / Memory |
Quad-Core A55 @1.2GHz · RAM 1GB · ROM 8GB |
| Hardware |
Keypad |
16 Keys (Virtual / Physical depending on model) |
| Hardware |
Supplement Light |
Yes |
| Hardware |
Fingerprint Sensor |
Z-ID (V5L only) |
| Hardware |
Casing Color |
Metallic Silver |
| Authentication |
Methods |
V5L: Face / Fingerprint / Palm (Opt.) / Card / Password · RFID: Face / Palm (Opt.) / Card / Password · QR: Face / Palm (Opt.) / Card / Password |
| Capacity |
Face Templates |
10,000 (1:N) |
| Capacity |
Fingerprint Templates |
10,000 (V5L only) |
| Capacity |
Palm Templates |
3,000 (Optional) |
| Capacity |
Card Capacity |
10,000 |
| Capacity |
User Capacity |
10,000 |
| Capacity |
Transaction Capacity |
200,000 |
| Password |
Max Length |
8 Digits |
| Speed |
Biometric Speed |
Fingerprint ≤0.5s · Face ≤0.35s · Palm ≤0.35s |
| Recognition Distance |
Face: 30–170cm · Palm: 15–40cm |
Touchless Biometric |
| Accuracy |
FAR |
Face ≤0.01% · Fingerprint ≤0.0001% · Palm ≤0.01% |
| Accuracy |
FRR |
Face ≤0.02% · Fingerprint ≤0.01% · Palm ≤0.17% |
| Algorithm |
Versions |
ZKFace V3.6 · ZKFingerprint V13.0/V10.0 · ZKPalmVein V20.1 |
| Card Type |
Supported |
125kHz ID (Std/Opt) · 13.56MHz IC (Opt) · Optional Multi-Tech Modules (DESFire EV1/EV2, FeliCa, HID Prox, HID iClass) |
| QR Code |
Support |
Dynamic QR via ZKBio CVAccess (QR model only) |
| Communication |
Interfaces |
TCP/IP · Optional Wi-Fi (2.4/5GHz) · Wiegand In/Out · RS485 · Aux In/Out · Lock · Door Sensor · Exit Button · Alarm |
| Standard Functions |
Features |
ADMS · DST · Photo/Event Capture · 14-Digit User ID · Access Levels · Anti-Passback · Tamper Alarm · Mask Detection · HTTPS/SSH Access |
| Optional Functions |
Features |
SIP Video Door Phone · ONVIF Profiles (S/T/G/C/Q/A) · Wi-Fi · Webserver |
| Video Intercom |
Support |
ZKTeco Private Protocol (TCP/IP) & Standard SIP |
| Supported Devices |
Intercom & Software |
VT07-B01 / VT07-B22L / VT07-B26L-W · ZKBio CVAccess · BioTalk Pro · ZKBio Zlink · ZKBio Zexus |
| Access Control |
Interface |
RS485 (DM10 Controller / Card Reader / Biometric Reader) |
| Power |
Supply |
DC 12V 3A |
| Environment |
Operating Temp |
−10°C to 45°C |
| Environment |
Humidity |
10%–90% RH (Non-condensing) |
| Dimensions |
Size (L×W×H) |
202.93 × 91.93 × 21.5 mm |
| Weight |
Net / Gross |
0.6 kg / 1.3 kg |
| Software |
Supported |
On-Premise: ZKBio CVAccess & ZKBio Time · Cloud: ZKBio Zlink |
| Installation |
Mounting |
Wall-mount (Asian Gang-box / Single Gang-box compatible) |
| Certifications |
Compliance |
ISO14001 · ISO9001 · CE · FCC |
