| Type |
Color Digital Multifunction Imaging System |
| Print Speed |
Letter: Up to 35 ppm (BW) / 30 ppm (Color)Legal: Up to 20 ppm (BW) / 18 ppm (Color)Ledger (11″×17″): Up to 20 ppm (BW) / 18 ppm (Color) |
| Functions |
Standard: Copy, Print (UFR II), Scan, Send, StoreOptional: Print (PCL, Adobe® PostScript® 3™), Fax (Up to 4 Lines) |
| Operation Panel |
8.4″ SVGA Full-Color TFT Screen |
| Memory |
2GB RAM (Std.) / 2.5GB RAM (Max.) |
| Hard Drive |
160GB (Std.) / Up to 1TB (Max.)Optional RAID1 Mirroring |
| Network Interface |
1000Base-T/100Base-TX/10Base-TOptional Wireless LAN |
| Other Interfaces |
USB 2.0 (Host ×2, Device ×1)Optional: Device Port, Serial, Copy Control Interface |
| Mailboxes |
100 User Inboxes, 1 Memory RX Inbox, 50 Confidential Fax Inboxes |
| Max Pages Stored |
6,000 Pages |
| Advanced Box |
15GB (Std.) / ~629GB (1TB HDD)Protocols: SMB, WebDAVMax Connections: SMB (32), WebDAV (12) |
| Memory Media |
Standard: USBOptional: SD, SDHC, CompactFlash, Memory Stick, Microdrive |
| Standard Paper Capacity |
Dual 550-sheet Cassettes + 100-sheet Bypass |
| Optional Paper Capacity |
Dual 550-sheet Cassettes, 2,700-sheet Paper Deck |
| Maximum Paper Capacity |
5,000 Sheets |
| Output Capacity |
250 Sheets (Std.) / 3,250 Sheets (with Finisher) |
| Supported Paper Sizes |
Up to 12″ × 18″, 11″ × 17″, Legal, Letter, Custom Sizes |
| Supported Paper Weights |
14 lb Bond – 140 lb Index (52–256 g/m²) |
| Duplexing |
Automatic Trayless Duplex (Executive to 12″ × 18″) |
| Special Media |
Plain, Recycled, Color, Bond, Heavy, Labels, Transparency, Tab, Letterhead, Envelopes |
| Warm-Up Time |
31 sec (Power On) / 15 sec (Sleep) / 7 sec (Quick Start) |
| Power Requirements |
120V AC, 60Hz, 15A |
| Power Consumption |
Max: 1.5 kW / Sleep Mode: 0.8W |
| Dimensions (W×D×H) |
36-5/8″ × 24-3/8″ × 28″ |
| Installation Space |
33-1/2″ × 28″ |
| Weight |
Approx. 333 lb (151 kg) |
| Scan Resolution |
Up to 600 × 600 dpi |
| Max Original Size |
Up to 11″ × 17″ |
| Copy Features |
First Copy Time: 5.4 sec (BW) / 8.1 sec (Color)1–999 CopiesZoom: 25%–400% |
| Security (Standard) |
Department ID, Single Sign-On, Secure Print, TPM, SSL, SNMPv1/v3, IP/MAC Filtering, HDD Erase/Lock, IPSec |
| Security (Optional) |
Removable HDD, HDD Encryption/Mirroring, Encrypted PDF, Secure Watermark, IEEE 2600.1 Certification |
| Environmental Certifications |
EPEAT® Rated, ENERGY STAR Qualified, RoHS, Blue Angel, WEEE |
